Axopar 28 Open

Specifications

Technical Specifications

  • Overall length: Incl. Bathing Platforms 9,20 m (30ft 1in)
  • Beam: 2,95 m (9ft 8in)
  • Dry weight: Weight (excl. Engine) 1770 kg (3902 lbs) - 1840 kg (4056 lbs)
  • Batteries:
  • Fuel capacity: 300 l (63.4 gal)
  • Water capacity:

Engine Options

  • Max speed range: 32-48 kts
  • 1 x 200hp V6 Mercury
  • 1 x 300hp V8 Verado
  • 1 x 350hp L6 Verado
  • 2 x 200hp V6 Mercury
Axopar Boats, Axopar 28 Open

Standard Equipment

▶ Make Enquiry

HULL AND DECK: 130mm added length and 50mm added width, raised hull sides by 80mm, softened spray rails and rounded keel shape. New stringer system based on 37 range. Improved shape and water deflection on bow thruster flanges. Vinylester resin for the first coat of the hull in GRP material, New anti-skid pattern on deck and deck hatches, enlarged service hatch on fore deck, Revised large bumper list with improved cushioning in grey colour, Wraparound windscreen and side windows in toughened glass and tinted light green with aluminium window profile painted in white, Pulpit and cockpit handles in hand polished stainless steel, 6* Stainless steel cleats aft, mid and bow, Fender storage on aft Deck SB and Port sides, Widened bathing platform with integrated Esthec Platinum decking with and telescopic bathing ladder, Self-draining deck with large diameter scuppers, Integrated engine bracket for outboard engines. Axopar 3D lettering on hull sides and model designation on side glasses.

HELM CONSOLE: Soft Touch painted dashboard and console panel, helm panel with passenger side grab rail, Illuminated push buttons and Axopar logo on glass panel, high-gloss helm exclusively in conjunction with factory-installed GPS and Mercury Pre-rig, Leather steering wheel with Axopar logo, 2 x cup holders, 12V power outlet, Compass, Fabric document pocket on console wall, Walnut foot rest.

LAYOUT AND SEATING: Walk-around deck with sociable reshaped L-sofa on foredeck and open aft deck area with enlarged storage under deck with integrated locker for windlass / bow thruster battery, Lowered floor level in cockpit for driving while standing, Driver and co-pilot seats with flip-up front / swivel function and outer armrests, Storage locker under co-pilot seat, Four back seats with outer armrests and storage underneath, ”Silvertex” Taupe, Graphite, Sterling and Cobre material on driver/co-pilot seats and aft sofa.

ELECTRICS:Main control panel with twin battery switches and automatic fuses for direct supply and 12V outlet located in cockpit, Main fuse panel with automatic fuses and 12V outlet located in Deck stowage / toilet area, Led roof spot lights 4pcs, 2 LED spot lights in Deck stowage / toilet, Light mast with anchor light and integrated loops for courtesy flags, Integrated LED navigation lights, Windscreen linked dual wiper arms, Electric bilge pumps x 2, Signal horn. Carbon monoxide detector in cabin, Fire alarm in cabin, Fuel sensor Vema

FRONT DECK STOWAGE AREA/TOILET: Enlarged storage area in centre console / optional toilet with raised interior finish with headliner and toiled door in double mould integrated window, varnished oak back panel with integrated mirror

OTHER: Aluminium fuel tank 300l (/240 EPA)l, 2 kg fire extinguisher, Manual bilge pump, Harbour cover for helm and driver/co-pilot seats and separate harbour cover for aft sofa, Flagpole.

Extra Equipment

▲ Top

BRABUS LINE TRIM PACKAGE
BRABUS LINE COLOR UPGRADE BLUE (ONLY W. BL)
BRABUS LINE COLOR UPGRADE GREY (ONLY W. BL)
PREMIUM PACKAGE, SILVERTEX
• Table in Esthec Platinum on foredeck • Foredeck seat cushions and back rest • Sun bed on foredeck • Harbour cover for foredeck • Mooring package: incl. 4 x fenders, 4 x fender covers with axopar logo, 4 x fender ropes, 4 x mooring ropes 14mm/10m, 5kg Anchor, 30m Anchor rope
PREMIUM PACKAGE, NIROXX
DAYCRUISER AFT CABIN (NOT AVAILALBLE WITH WETBAR)
WETBAR (ONLY WITH FRESHWATER OPTION, NOT AVAILABLE WITH DC CABIN )
TOILET PACKAGE, ELECTRIC FW FLUSH
LIGHTING PACKAGE(LED DECK LIGHTS, COMFORM LIGHTING IN SALOON, ILLUMINATED 28 LOG
TOILET PACKAGE, MANUAL SEAWATER FLUSH
• Seawater flush, 40l septic tank, macerator, overboard discharge and dockside pump-out,
COMPLETE ESTHEC PACKAGE – PLATINUM/WHITE
• Esthec platinum complete exterior flooring in platinum colour with white caulking
OPTIONS
• Aft deck bench with stowage with cushion (not av. With: Wetbar and Day Cruiser)

• Antifouling, Grey or White
• Bowthruster Side-Power SE40
• Cooler in aft port storage
• Electric grill 220V (only with wet bar and shore power 220V)
• Electric windlass in bow, Engbo Midi 201 + remote control
• Electrical roof system Webasto
• Esthec only on aft cabin roof, Platinum/White, available with Daycruiser Cabin
• Extended wood floor in cabin, Walnut
• Fore deck cushions incl. backrest, Niroxx
• Fore deck cushions incl. backrest, Silvertex
• Freshwater system+45l tank
• Harbor cover for aft deck, Sunbrella Plus RED(av.Only w. Daycruiser Cabin)
• Harbor cover for fore deck, RED (incl. in premium pckg)
• Heater Webasto AT3900
• Hull colour Grey
• Interior, Seats Niroxx
• Protective window covers
• Refrigerator in aft port storage (n.a. with Audio upgr.2)
• Search light
• Shore power 230v with 20Ah charger
• Shower on aft deck (only w. freshwater option)
• Side rails
• Sun shade on foredeck, for stationary use
• Sundeck cushions for aft deck, Niroxx(av. Only with Daycruiser Cabin)

• Sundeck cushions on fore deck, Silvertex (only w. table)
• Table on foredeck, (incl. in premium package)
• Targa Arch with rod holders and roof rails
• Targa arch with roof rails
• Top loading refrigerator, Dometic CM 42l
• Trim tabs with joystick
• Two aft deck folding seats with table
• Underwater Lights
• Waterski pole
PRE-RIGGING
• Mercury upgrade package, Active Trim, VV Mobile, TDS
ELECTRONICS
• Chartplotter Garmin GPSmap 1222 Touch
• Chartplotter Garmin GPSmap 922
• Communication Garmin VHF 115i
• Intelliducer
• Radar GMR18 18HD
• Sonar module Garmin GSD
• Twin Chartplotter Garmin GPSmap 1222 Touch
• Twin Chartplotter Garmin GPSmap 922
AUDIO OPTIONS
• Audio upgrade1: 4 x speakers + 2ch amplifier
• Audio upgrade2: 1 x subwoofer + upgrade to 4ch amplifier
• Control unit for Fusion system, Helm
• Fusion Entertainment system, incl. 2 x speakers in cockpit

Disclaimer: The specifications are approximations and subject to variance. We reserve the right to make changes without future notice. Some equipment options may not be available.
